Wood, MDF and Particleboard Industry

Selection of air line, duct, cyclone, and filter systems for dust from cutting, sanding, chip conveying, and press areas.

Wood, MDF & Particleboard

Wood, MDF & ParticleboardBaghouse filters + spare parts

Industry solution

Wood, MDF and Particleboard Industry

Selection of air line, duct, cyclone, and filter systems for dust from cutting, sanding, chip conveying, and press areas. Dust load, operating temperature, maintenance access, and emission targets at each process point determine product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Wood, MDF & Particleboard Industry equipment scope

Filter, fan, filter bag, filter cage and auxiliary equipment selection by process

In wood, MDF, and particleboard production, wood chips, fibrous dust, sanding dust, and press fumes each require different capture methods and fire safety measures. Cyclones, baghouse filters, air equipment, ductwork, and chip conveying equipment are selected together with the process machinery.

Process filtration, fan, and equipment scope for Wood, MDF & Particleboard Industry

Process-based system approach

The filter housing, fan, ductwork, filter element, pulse-jet system and discharge/conveying equipment are not independent of one another; they are evaluated as components of the same operating point.

Information clarified before quoting

Suction airflow: Machine inlets, simultaneous use, and duct velocities
Dust/fiber structure: Chip size, sanding fineness, resin/moisture
Explosion/fire: Kst/Pmax or site risk classification
Filter load: Inlet concentration and operating time
Conveying line: Rotary valve, screw conveyor, hopper, and silo layout

Equipment scope by process point

Process Dew Point	Filter / dust-fume solution	Fan, ductwork and conveying equipment	Critical selection grade
Cutting and sizing	On-machine extraction + central baghouse filter	High-flow chip/sawdust air-handling equipment and ductwork	Coarse chips, high conveying velocity, and duct buildup
Sanding and calibration	Surface-filtration baghouse for fine dust	High-vacuum air-handling equipment, damper, and spark-detection compatibility	Very fine/combustible dust and low emission
Crushing, chip, and fiber preparation	Cyclone + baghouse filter	Pneumatic conveying air handling equipment, rotary valve, and conveyor	Fibrous material, wrapping, and fire load
Press and hot process	Fume/particulate extraction, suitable filtration	Exhaust fan equipment, duct, and damper	Resin, temperature, sticky aerosols, and odor
Silo and hopper	Silo-top filter and transfer dedusting	Rotary valve, screw conveyor, bucket elevator, and discharge fan equipment	Bridging, explosive atmosphere, and level control

Equipment groups used in this industry

Chip conveying fan

Pneumatic conveying of chips/fibers at high air velocity.

Sanding dust fan

High vacuum and stable suction for fine dust lines.

Cyclone air equipment

Provides flow for the pre-separator and chip storage line.

Process exhaust air handling equipment

Fume/air extraction on press and coating lines.

Product families we offer for Wood, MDF & Particleboard Industry

Wood chip baghouse filter

Suitable inlet and cleaning design for fibrous, bulky loads.

Antistatic filter bag

Media suited to risk analysis for combustible wood/MDF dust.

Cyclone pre-separator

Separates coarse chips before the main filter.

Spark/fire compliance equipment

Coordination with detection, isolation, and discharge arrangement.

Rotary valve, screw conveyor, and conveyor

Enclosed transfer of chips and dust.

Air handling equipment, duct, and damper

Machine-based balancing and service access.

How do we determine capacity and technical specifications?

Exact capacity is not set by a catalog name; it is determined by process flow rate, system pressure, temperature, material/dust behavior and discharge continuity.

technical data	Required site / process information	Impact on selection
Suction flow rate	Machine extraction points, simultaneous use, and duct velocities	Determines chip settling and capture.
Dust/fiber structure	Chip size, sanding fineness, resin/moisture	Determines the filter and discharge type.
Explosion/fire	Kst/Pmax or site risk classification	Determines the scope of antistatic media and safety.
Filter load	Inlet concentration and operating duration	Affects the need for a cyclone and the filter area.
Conveying line	Rotary valve, screw conveyor, hopper, and silo layout	Prevents bridging and production stoppages.
