Concrete Plants

Compact baghouse filters, air handling equipment, and spare parts supply for cement silos, hoppers, mixers, transfer, and filling points.

Concrete Batching Plants

Concrete Batching PlantsBaghouse filters + spare parts

Industry solution

Concrete Plants

Compact baghouse filters, air handling equipment, and spare parts supply for cement silos, hoppers, mixers, transfer, and filling points. Dust load, operating temperature, maintenance access, and emission targets at each process point determine the product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Concrete Batching Plants equipment scope

Filter, fan, filter bag, filter cage and auxiliary equipment selection by process

In a concrete batching plant, cement silo filling, the aggregate hopper, weighing, mixing, and loading points generate short but high dust spikes. Compact filters, silo safety equipment, fans, and discharge equipment are selected according to the plant's cycle.

Process filtration, fan, and equipment scope for Concrete Batching Plants

Process-based system approach

The filter housing, fan, ductwork, filter element, pulse-jet system and discharge/conveying equipment are not independent of one another; they are evaluated as components of the same operating point.

Information clarified before quoting

Fill rate: Tanker discharge speed and number of silos
Silo pressure: Vent valve and filter ΔP
Cycle: Mixer filling frequency and simultaneous points
Dust/moisture: Cement, ash, silica, and damp aggregate
Dosing capacity: Screw diameter, motor, and weighing time

Equipment scope by process point

Process Dew Point	Filter / dust-fume solution	Fan, ductwork and conveying equipment	Critical selection grade
Cement silo filling	Silo-top pulse-jet filter	Pneumatic filling line and pressure relief equipment	Filling flow rate, silo pressure, and overfilling
Aggregate hopper feed	Hood-based local dust collection	Transfer air-handling equipment, ductwork, and belt conveyor	Wind, coarse/moist aggregate, and open surfaces
Cement/additive weighing	Weighing hopper vent filter	Compact fan, flexible connection, and screw conveyor	Precision dosing and false air
Mixer filling/discharge	Mixer-top filter or central extraction	Exhaust fan equipment, damper, and duct	Sudden dust spikes and moist, sticky dust
Bag/big-bag additive discharge	Cabinet-type local filter	Screw feeder and extraction air handling equipment	Operator exposure and product loss

Equipment groups used in this industry

Silo filter fan equipment

Safely vents the air inside the silo during filling.

Mixer dedusting fan

Captures the dust peak during filling.

Hopper transfer fan equipment

Local extraction at aggregate transfer and weighing points.

Additive discharge fan

Protects the operator zone at the bag/big-bag filling station.

Product families we offer for Concrete Batching Plants

Filter on top of silo

Compact pulse-jet unit for cement and mineral additive silos.

Filter bag/cartridge

Surface filtration suited to fine cement dust.

Pulse valve and diaphragm

Silo filter maintenance/spare part.

Silo safety equipment

Mechanical compatibility with the pressure relief and level system.

Spiral and rotary

Cement/additive dosing and enclosed transfer.

Local mixer/hopper filter

Centralized or point-source solution depending on the plant cycle.

How do we determine capacity and technical specifications?

Exact capacity is not set by a catalog name; it is determined by process flow rate, system pressure, temperature, material/dust behavior and discharge continuity.

technical data	Required site / process information	Impact on selection
Filling rate	Tanker unloading rate and number of silos	Determines the silo filter area.
Silo pressure	Discharge valve and filter ΔP	Affects silo safety.
Cycle	Mixer filling frequency and simultaneous points	Determines air handling equipment/pulse capacity.
Dust/moisture	Cement, ash, silica, and moist aggregate	Determines media and cleaning type.
Dosing capacity	Screw diameter, motor, and weighing time	Determines production speed.
