Iron and Steel Industry

Filter, fan, ductwork and expansion joint solutions for high-temperature dust in melting, casting, rolling, slag and material transfer lines.

Iron & Steel Industry

Iron & Steel IndustryBaghouse filter + spare parts

Industry solution

Iron and Steel Industry

Filter, fan, ductwork and expansion joint solutions for high-temperature dust in melting, casting, rolling, slag and material transfer lines. Dust loading, operating temperature, maintenance access and emission targets at each process point determine the product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Iron & Steel Industry equipment scope

Filter, fan, filter bag, filter cage and auxiliary equipment selection by process

In iron and steel plants, melting fumes, hot metal oxide, slag, and mill scale cannot be handled with the same system approach. Extraction hoods, ductwork, baghouse filters, process air equipment, compensators, and discharge equipment are evaluated together based on process temperature and fume load.

Process filtration, fan, and equipment scope for Iron & Steel Industry

Process-based system approach

The filter housing, fan, ductwork, filter element, pulse-jet system and discharge/conveying equipment are not independent of one another; they are evaluated as components of the same operating point.

Information clarified before quoting

Flow rate and fume peaks: Furnace cycle, lid/charging events and simultaneous extraction points
Gas temperature: Continuous/peak temperature and spark behavior
Dust composition: Metal oxide, carbon, slag and oily fume
System pressure: Hood, ductwork, damper and filter ΔP
Discharge: Hopper, rotary valve, screw conveyor and container layout

Equipment scope by process point

Process Dew Point	Filter / dust-fume solution	Fan, ductwork and conveying equipment	Critical selection grade
Electric arc / induction furnace	Primary-secondary fume extraction, baghouse filter, or suitable pre-separation	High-pressure ID fan, water-cooled ductwork/suitable expansion joint	Sudden fume peaks, sparks, high temperature and carbon loading
Ladle, casting and transfer	Hood-based local fume collection, baghouse connection	Booster fan, damper and high-temperature ductwork	Moving source, lid opening and false-air control
Slag crushing and screening	Cyclone pre-separator + abrasion-resistant baghouse filter	Dust collection fan, rotary valve and screw conveyor discharge	Abrasive coarse particles, sparks and hopper wear
Rolling mill and scale points	Local extraction, cartridge/bag filter, or a suitable separator	Exhaust fan, ductwork, damper and transfer equipment	Oily fume, metal oxide and maintenance access
Shot blasting, grinding and surface cleaning	Cartridge or bag-type dry dust collection	Local extraction fan, cyclone separator and rotary/drum discharge	Fine metal dust, wear and combustible dust review

Equipment groups used in this industry

Furnace ID fan

High-flow, high-pressure duty in the furnace's primary/secondary extraction system.

Booster air equipment

Meets system pressure requirements in long ductwork and central baghouse lines.

Slag dedusting fan

Wear-protected operation for crushing-screening and transfer dust.

Local fume extraction fan

Zone-based extraction at ladle, grinding and shot-blasting points.

Product families we offer for Iron & Steel Industry

High-flow baghouse filter

Modular baghouse for furnace and central fume collection systems.

High-temperature filter bags

Aramid, P84, PTFE or suitably surface-treated media selection.

Filter cages

Silicone/cataphoresis-coated or stainless, venturi-compatible filter cage.

Cyclone separator and spark pre-separation

Reducing coarse hot particles before the main filter.

Process fans and dampers

Fan, damper and vibration control matched to the flow-pressure operating point.

Expansion joint, rotary valve and screw conveyor

Combined solution for hot-duct expansion and filter hopper discharge.

How do we determine capacity and technical specifications?

Exact capacity is not set by a catalog name; it is determined by process flow rate, system pressure, temperature, material/dust behavior and discharge continuity.

technical data	Required site / process information	Impact on selection
Flow rate and fume peaks	Furnace cycle, lid/charging events and simultaneous extraction points	Determines the fan and filter area.
Gas temperature	Continuous/peak temperature and spark behavior	Changes the media, ductwork and pre-separation decision.
Dust composition	Metal oxide, carbon, slag and oily fume	Determines bag surface and abrasion protection.
System pressure	Hood, ductwork, damper and filter ΔP	Determines the fan motor and operating point.
Discharge	Hopper, rotary valve, screw conveyor and container layout	Affects continuous operation and fire risk.
