Cement Plants

Baghouse filter, process air handling equipment, and spare parts solutions for crusher, raw mill, clinker line, silo, packaging, and transfer points. Dust load, operating temperature, maintenance access, and emission targets at each process point determine the product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Equipment scope for the cement industry

Filters, fans, filter bags, cages, and conveying equipment matched to each process point in a cement plant

A cement plant does not have just one filtration need; from the crusher to the raw mill, from the kiln/preheater line to clinker cooling, and from the cement mill to silo and packaging, every point differs in dust load, temperature, flow rate, and maintenance risk. Hantech Filter therefore addresses filter housings, fans, filter bags, cages, pulse systems, rotary valves, screw conveyors, elevators, air slide fabric, and conveyors together on a process-by-process basis.

Process filtration, fans, and spare parts scope for cement plants

Process-based cement filtration

The correct product for raw meal, clinker, cement, coal, silo, and packing lines is selected based on flow rate, temperature, dust type, and emission target.

Information that must be clarified before quoting

Process point: raw meal, kiln, clinker cooler, cement mill, coal mill, silo, packaging, or transfer
Airflow rate, air handling equipment nameplate, motor power, duct diameter, and existing pressure drop
Dust type, temperature, moisture, abrasion, alkali/chemical load, and emission target
Existing filter bag size, filter cage diameter/wire count, venturi, and pulse valve information
Hopper outlet, rotary valve, screw conveyor, elevator, air slide, and conveyor capacity

Filter and air handling equipment scope by process point

Cement process	Filter / dust collection	Air handling equipment and conveying equipment	Critical selection grade
Crusher, raw material transfer, and stockyard	Local dust collection filter, cyclone pre-separator, transfer point hood	Dust collection air-handling equipment, ductwork, rotary airlock, screw/conveyor discharge	Abrasive coarse dust, impact loading, maintenance access, and continuous hopper discharge
Raw meal mill and separator line	Flour mill filter, system filter, high-flow baghouse filter	Raw meal system air handling equipment, mill air handling equipment, separator air handling equipment, ID fan integration	High flow rate, temperature fluctuation, fine raw-meal dust, and stable differential pressure
Kiln, preheater, and bypass area	Kiln/preheater filter, bypass filter, process gas dust collection	ID fan, kiln exhaust fan, primary/secondary air fans, and process fans	Hot gas, chemical load, alkali/chlorine risk, filter bag media, and insulation
Clinker cooling	Clinker cooler filter, cooler dedusting bag filter	Clinker cooler fans, mantle cooling fans, cooler exhaust fan	Hot/abrasive dust, sudden load changes, fan operating point, and spark risk
Cement mill	Cement mill filter, system filter, separator/product filter	Cement mill fan, separator fan, filter fan	Fine product dust, high efficiency, low emission, and bag surface filtration
Coal mill and fuel preparation	Coal mill filter, antistatic filter bags, and safe discharge	Coal mill fan, inerting/exhaust line, and explosion vent compatibility	ATEX risk, antistatic media, temperature, and safety equipment coordination
Silo, packaging, and loading	Silo-top filter, packing filter, hopper/bag filling filters	Silo venting fan equipment, local extraction fan equipment, rotary/air slide discharge	Very fine cement dust, low leakage, easy bag replacement, and continuous dispatch
Conveying and dosing lines	Transfer point filters, local extraction hoods, enclosed transfer dust collection	Integration of screw conveyor, elevator, air slide fabric, air slide, rotary valve, and conveyor	Material flow, sealing, capacity matching, and planned maintenance

Equipment groups used in cement plants

ID fan / kiln exhaust fan

High flow rate and pressure requirement at the main draft points of the kiln, preheater, and raw meal system.

Raw meal system air handling equipment

Flow/pressure balance together with the raw mill, separator, and system filter.

Clinker cooler fans

High-temperature and wear control at cooler cells, shell cooling, and cooler exhaust lines.

Cement mill fan

Stable flow rate, low vibration, and energy efficiency for the mill filter and separator line.

Coal mill fan

Coal dust and temperature-controlled operation together with antistatic/safety scope.

Local dust collection air handling equipment

Local extraction solutions at crusher, transfer, packaging, silo, and loading points.

Product families we supply for the cement industry

Baghouse filter systems

Filters for clinker cooling, raw meal mill, cement mill, coal mill, silo, packaging, and transfer points.

Filter Bags

Polyester, antistatic PE, aramid, PPS, P84, PTFE/ePTFE membrane, and fiberglass options are selected based on temperature, humidity, alkalinity, and emission target.

Filter cages

Galvanized, cataphoresis-coated, silicone-coated, and stainless steel cages; venturi, wire count, diameter, and bag compatibility are checked together.

Pulse jet valves

Bag cleaning via diaphragm valve, solenoid, air tank, blow pipe, and differential pressure control.

Rotary airlock / rotary valve

Sealed material transfer at filter hopper outlets, silos, and pneumatic/enclosed discharge lines.

Screw conveyor, elevator, and conveyor

Dust control at screw conveyors, bucket elevators, enclosed conveyors, and transfer points in dust/clinker/cement handling.

Air slide fabric / air slide

Air permeability, pressure loss, and leak-tight flow control in cement and raw meal conveying lines.

Field measurement and retrofit

Revision scope determined by reporting flow rate, pressure loss, filter bag life, and emission issues on the existing filter/fan line.

How should capacity and specification data be read?

technical data	Information requested on the cement page	Why does it matter?
Airflow / capacity	m³/h process air, number of local suction points, duct diameter, fan nameplate	Filter area, air handling equipment capacity, and duct cross-section are determined based on this data.
Temperature	Continuous and peak temperature; distinction between clinker cooler, raw meal/coal mill, and kiln line	Changes the selection of filter bag media, cage coating, insulation, and safety equipment.
Dust characteristics	Raw meal, clinker, cement, coal, gypsum, limestone; particle size, moisture, and abrasiveness	Determines media, abrasion protection, hopper discharge, and cleaning regime.
Emission target	Regulatory/plant target, stack measurement, and leak complaints	Affects the choice between standard felt, microfiber, or ePTFE membrane.
Differential pressure	Existing ΔP trend, pulse period, and compressor capacity	A critical indicator for filter bag life, valve consumption, and energy cost.
Discharge and conveying	Rotary valve, screw conveyor, air slide, bucket elevator, conveyor capacity, and blockage history	Even if the filter is operating, insufficient hopper discharge causes dust leakage and downtime.

Cement quote review matrix

These headings are not success percentages; they are the critical variables we verify in the field when selecting filters, fans, bags, cages, and conveying equipment for a cement plant.

Airflow and fan operating pointCritical check

Temperature and filter bag mediaCritical control

Pulse-jet and compressed airCritical control

Rotary valve / screw conveyor / elevator dischargeCritical control

Typical problems we solve in the field

High temperature and short bag life in the clinker cooler filter
Insufficient suction or high energy consumption in raw meal system equipment
Fine cement dust leakage in packaging and silo filters
Bag tearing caused by cage/venturi mismatch
Hopper blockage caused by a capacity mismatch between the rotary valve, screw conveyor, bucket elevator, or air slide
