Ceramics and Porcelain Industry

Filter bag, cyclone and air handling equipment solutions for dust from raw material preparation, pressing, glaze preparation, drying and kiln areas.

Ceramics & Porcelain

Ceramics & PorcelainBaghouse filters + spare parts

Industry solution

Ceramics and Porcelain Industry

Filter bag, cyclone and air handling equipment solutions for dust from raw material preparation, pressing, glaze preparation, drying and kiln areas. Dust loading at the process points, operating temperature, maintenance access and emission target determine the product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Ceramics and Porcelain Industry equipment scope

Filter, fan, filter bag, filter cage and auxiliary equipment selection by process

In ceramics and porcelain production, raw material preparation, spray dryers, presses, glazing, kilns, and finishing lines generate fine mineral dust and hot gas. Cyclones, baghouse filters, air handling equipment, filter bags/cages, and material transfer systems are selected on a process-by-process basis.

Process filtration, fans, and equipment scope for the Ceramics and Porcelain Industry

Process-based system approach

The filter housing, fan, ductwork, filter element, pulse-jet system and discharge/conveying equipment are not independent of one another; they are evaluated as components of the same operating point.

Information clarified before quoting

Mineral/dust: Silica, clay, feldspar, pigment, and particle size distribution
Temperature/moisture: Spray dryer and kiln conditions
Airflow: Dryer, press, and local suction points
Product recovery: Cyclone/filter product quality
Conveying: Granule elevator, rotary valve, and conveyor

Equipment scope by process point

Process Dew Point	Filter / dust-fume solution	Fan, ductwork and conveying equipment	Critical selection grade
Raw material crushing/grinding	Cyclone + baghouse filter	Mill fan equipment, rotary valve, and conveyor	Silica/mineral dust and wear
Spray dryer	Heavy-duty cyclone + suitable final filter	Dryer ID fan and hot gas duct	Damp fine dust, temperature, and product recovery
Press and granule feeding	Local dust collection	Press extraction air handling equipment, elevator, and enclosed transfer	Fine granules, vibration, and leakage
Glaze preparation/spraying	Wet/dry-suitable extraction and filtration	Exhaust fan equipment, damper, and duct	Pigment, humidity, and sticky aerosol
Kiln/finishing	Hot gas/dust filter and grinding extraction	Kiln exhaust air handling equipment, expansion joint, and local air handling equipment	High temperature, chemical gas, and fine silica

Equipment groups used in this industry

Spray dryer ID fan equipment

Maintains the flow/pressure balance of the drying circuit.

Mill fan equipment

Operates on the grinding and product separation line.

Press dedusting air handling equipment

Local extraction around granule feeding and the press.

Kiln exhaust air handling equipment

Manages hot gas and process ventilation.

Product families we offer for the Ceramics and Porcelain Industry

Mineral powder baghouse

For abrasive fine ceramic dust.

Cyclone pre-separator

Reduces spray dryer/crushing load.

Filter bag and cage

Based on temperature, humidity, and pigment.

Process air handling equipment and expansion joint

For dryer/kiln lines.

Rotary valve, screw conveyor, and bucket elevator

Enclosed transfer of granules/dust.

Local press/finishing filter

Dust control at the welding source.

How do we determine capacity and technical specifications?

Exact capacity is not set by a catalog name; it is determined by process flow rate, system pressure, temperature, material/dust behavior and discharge continuity.

technical data	Required site / process information	Impact on selection
Mineral/dust	Silica, clay, feldspar, pigment, and particle size distribution	Determines wear/media requirements.
Temperature/moisture	Spray dryer and kiln conditions	Determines filter bag and condensation risk.
Flow rate	Dryer, press, and local extraction points	Determines the air handling equipment/filter.
Product recovery	Cyclone/filter product quality	Affects separation design.
Conveying	Granule elevator, rotary valve, and conveyor	Affects breakage and continuity.
