Asphalt Plants

High-temperature filter bags, filter cages, fans, and filter retrofit solutions for dust from dryers, screening, mixers, and flue gas lines.

Asphalt Plants

Asphalt PlantsBaghouse filters + spare parts

Industry solution

Asphalt Plants

High-temperature filter bags, filter cages, fans, and filter retrofit solutions for dust from dryers, screening, mixers, and flue gas lines. Dust load, operating temperature, maintenance access, and emission targets at each process point determine the right product selection.

Baghouse filter / dust collector selection

Filter bag and filter cage compatibility

Pulse-jet valve and compressed air system

Rotary airlock, screw conveyor and fan integration

Request a quote for this sector

Asphalt plant equipment scope

Filter, fan, filter bag, filter cage and auxiliary equipment selection by process

In asphalt plants, dryer gas, hot aggregate dust, the screen/mixer area, and filler transfer generate high temperatures and wear. The baghouse, cyclone, ID fan, hot-gas expansion joint, filter bag/cage, and filler conveying system are selected together.

Process filtration, fan, and equipment scope for asphalt plants

Process-based system approach

The filter housing, fan, ductwork, filter element, pulse-jet system and discharge/conveying equipment are not independent of one another; they are evaluated as components of the same operating point.

Information clarified before quoting

Gas temperature: Normal/peak and low-load condition
Airflow: Drum capacity, false air, and moisture
Dust load: Filler amount depending on aggregate and fuel type
Fuel/gas: Fuel type, combustion quality, and acid/moisture
Filler conveying: Rotary valve/screw conveyor/elevator capacity

Equipment scope by process point

Process Dew Point	Filter / dust-fume solution	Fan, ductwork and conveying equipment	Critical selection grade
Drying drum	Cyclone pre-separator + high-temperature baghouse	Dryer ID fan and hot gas duct	Temperature peaks, sparks, humidity, and fine filler
Hot screening and mixer	Enclosed extraction and main filter connection	Booster/local fan and damper	Hot leaking gas and maintenance access doors
Filler silo	Filter on top of silo	Filler air handling equipment, rotary valve, screw conveyor, and bucket elevator	Very fine dust and continuous recovery
Aggregate transfer	Local filter/cyclone at the transfer point	Belt conveyor extraction fan	Corrosive coarse powder
Stack and clean gas line	Baghouse outlet/emission control	ID fan, stack, and compensator	Air handling equipment wear, ΔP, and emissions

Equipment groups used in this industry

Dryer ID fan

Main draft fan of the drum–baghouse–stack system.

Filler transfer air handling equipment

Dust control at silos and dosing points.

Aggregate dedusting air equipment

Abrasive dust extraction at crushing/transfer points.

Booster air equipment

Handles long duct runs or local extraction resistance.

Product families we offer for asphalt plants

Asphalt baghouse

Filter system for high temperature and abrasion.

Aramid/P84/PTFE bags

Media selected according to temperature and gas chemistry.

Silicone coated cage

Cage compatible with high-temperature bags.

Cyclone pre-separator

Reduces coarse hot particles.

ID fan and compensator

Hot gas draft and thermal movement control.

Filler rotary valve/screw conveyor/bucket elevator

Recovery of the collected mineral dust.

How do we determine capacity and technical specifications?

Exact capacity is not set by a catalog name; it is determined by process flow rate, system pressure, temperature, material/dust behavior and discharge continuity.

technical data	Required site / process information	Impact on selection
Gas temperature	Normal/peak and low-load condition	Determines the filter bag media.
Flow rate	Drum capacity, air leakage, and humidity	Determines filter/air handling equipment size.
Dust load	Filler amount depending on aggregate and fuel type	Affects the cyclone/filter area.
Fuel/gas	Fuel type, combustion quality, and acid/moisture	Affects the filter bag's chemical resistance.
Filler conveying	Rotary valve/screw conveyor/bucket elevator capacity	Determines baghouse continuity of operation.
